ABB 5SHY3545L0021 5SXE10-0181 Thyristor module

ABB 5SHY3545L0021 5SXE10-0181 Thyristor module:

• Product Type: Thyristor module, potentially used in high-voltage direct current (HVDC) transmission, flexible AC transmission systems (FACTS), or other high-power applications.
• Voltage & Current Speculation: Based on similar models like 5SHY35L4520, the rated voltage is estimated to be in the thousands of volts (e.g., 6500V), and the rated current may be around 1000A (inferred from the “3545” in the model number).

5SXE10-0181

• Rated Voltage: 6500V
• Rated Current: 1000A
• Switching Loss: 5.0J
• Conduction Loss: 2.5V
• Switching Frequency: 2kHz
• Junction Temperature: 175°C
• Weight: 15kg
• Dimensions:
  • Length: 300mm
  • Width: 250mm
  • Height: 150mm
• Mounting Hole Distance: 250mm
• Features:
  • Advanced digital signal processing technology for high-speed computation and response, enabling rapid fault detection and protection actions.
  • Supports multiple communication interfaces and protocols (e.g., IEC 61850, Modbus) for system monitoring and data exchange.
  • User-programmable logic and parameter settings for customized protection and control functions.
