ABB REG216 216VC62A HESG324442R13/B Digital Generator Protection Module

REG216 Digital Generator Protection Module

• Functions and Applications
  It features reduced idle current and self-checking capabilities, suitable for various power system applications, including protection for generators and transformers. It offers multiple DC output models (32V, 48V, and 70V), along with an additional 5VDC, 500mA regulated logic power supply.
• Physical Characteristics
  DC input range: 36 to 312V; Output: 24V DC, 150W. The auxiliary DC power supply unit has short-circuit and overload protection.
• Communication and Interfaces
  Supports serial communication, equipped with a serial cable for setup and programming, as well as interfaces for data monitoring and control.
• Protection Features
  Provides comprehensive protection functions, including differential protection, overcurrent protection, undervoltage protection, etc. The differential protection based on the vector product principle ensures high stability during through-faults and saturation.

216VC62A HESG324442R13/B Input/Output Module

• Electrical Parameters
  Independently powered; Input voltage: 18 – 56VDC; Nominal power supply: 24VDC.
• Communication and Protocol
  Has embedded support for the Genius Bus protocol, enabling I/O data exchange with the Genius Bus master station via the network.
• Processing Capability
  Update rate per channel: 4ms. Equipped with software-adjustable filter responses (None, 8, 16, 32, 64, 128, 256, 512, and 1024ms) to stabilize input signals.
• Diagnostic Functions
  Self-diagnostic capabilities for detecting under-range, over-range, high alarm, and low alarm; configurable open-circuit output settings.
• Accuracy
  Typical accuracy: 0.2% of full scale; Maximum accuracy: 0.5% of full scale.
• Other Parameters
  Output frequency: 10/100Mbps; Processing speed: 50MHz; Program capacity: 16MB; Data capacity: 256MB. Certification: CE. Operating temperature: 0 to 60°C; Environmental humidity: 5 to 95% (non-condensing); Weight: 0.2 kg.
