EMERSON PR9268/207-100 is a sensor used for precision measurement in industrial control systems. Its relevant parameters are as follows:
Sensitivity: 28.5mV/mm/s (723.9mV/in/s) at 80Hz, 20°C, and 100kohm, with a tolerance of ±5%.
Measurement Range: ±1500μm (59,055μin).
Frequency Range: 4 to 1000Hz (240 to 60,000cpm), ±3dB.
Natural Frequency: 4.5Hz ±0.75Hz at 20°C.
Transverse Sensitivity: 0.13 at 110Hz for PR9268/20x-x00.
Vibration Amplitude: Mechanical limit is 3000μm (4000μm peak-to-peak).
Amplitude Linearity: Less than 2%.
Maximum Acceleration: 10g (98.1m/s²) peak-to-peak continuously, 20g (196.2m/s²) peak-to-peak intermittently.
Maximum Transverse Acceleration: 2g (19.62m/s²).
Damping Coefficient: Approximately 0.56 at 20°C, and about 0.42 at 100°C.
Resistance: 1875Ω ±10%.
Inductance: ≤90mH.
Active Capacitance: <1.2nF.
Operating Temperature: -20°C to +100°C (-4°F to +212°F).
Relative Humidity: 0 to 100% (non-condensing).
Protection Class: IP55.
Material: Durable stainless steel.
Weight: 930g.
