ENTERASYS A4H124 – 24FX is a 24-port fiber optic managed switch of the A4 series from ENTERASYS. It is mainly used in network environments such as industrial automation. The following is a detailed introduction:
- Port Configuration: It has 24 100Base – FX fiber optic ports, which can provide high-speed Ethernet connections and are suitable for scenarios that require long-distance transmission or have high requirements for electromagnetic interference resistance. At the same time, it is also equipped with 2 Gigabit Small Form-factor Pluggable (SFP) ports, which are used to connect other high-speed devices or as uplink ports to achieve network aggregation with higher bandwidth.
- Performance Parameters: The switching capacity is 12.8Gbps, which can meet the needs of rapid forwarding of a large amount of data. The forwarding rate is 9.5Mpps, which can ensure the efficient transmission of data packets in the network and reduce latency and packet loss. It supports 4,096 virtual interfaces (VLANs), which can flexibly divide network areas and improve the security and management efficiency of the network. The MAC address table size is 16,000 entries, which can store a large amount of MAC address information for quick lookup and forwarding of data frames.
- Functional Features: It supports a variety of remote management protocols, such as SNMP2, SNMP, RMON, Telnet, HTTP, TFTP, SSH, etc., which is convenient for administrators to configure, monitor, and manage the switch through the network. It has functions such as flow control, BOOTP support, IGMP snooping, system log support, port mirroring, and DiffSserv support, which can effectively manage and optimize network traffic. It supports both half-duplex and full-duplex modes and can automatically adjust the working mode according to the actual network environment. It supports the Spanning Tree Protocol (STP) and the Rapid Spanning Tree Protocol (RSTP), which can prevent the generation of network loops and improve the stability of the network. In addition, it also provides functions such as Quality of Service (QoS), RADIUS support, and Link Aggregation Control Protocol (LACP) to meet the network performance and security requirements of different users.
- Physical Characteristics: It adopts a desktop-style case design, with dimensions of 17.4 inches × 14.5 inches × 1.7 inches and a weight of approximately 10.8 pounds, making it easy to install and place on an office desk or in a cabinet. The operating voltage is AC 120/230 volts (50 – 60 Hz), which can adapt to different power supply environments.
