FOXBORO P0926GX FBM233 Ethernet communication module

In stock

Warehouse: Spot

Condition: New original inventory

Warranty: 100% Perfect Functionality

Available for sale: nationwide, overseas

Warranty period: one year

Imported or not: Yes

Shipping location: Yuanmiao, Guizhou

FOXBORO P0926GX FBM233 is an Ethernet communication module with the following parameters:

Basic Information:
- Type: I/O module
- Manufacturer: FOXBORO (a subsidiary of Schneider Electric)
- Product Type: Ethernet communication module
Communication Parameters:
- Communication Type: Ethernet
- Transmission Rate: 10Mbps or 100Mbps
- Communication Protocol: UDP/IP or TCP/IP
- IP Address: Fixed or DHCP
- Maximum Number of Connected Devices: Each FBM233 can communicate with up to 64 field devices
- Data Connections: Up to 2000 DCI block connections
- Transmitted Data Types: 2-byte or 4-byte signed or unsigned integers, 4-byte IEEE single-precision floating-point values, binary values
- Fastest Allowed ECB Block Cycle: 500 milliseconds
Power Supply Parameters:
- Input Voltage Range (Redundant): 24V DC (+5%, -10%)
- Power Consumption: Maximum 7W per module
- Heat Dissipation: Maximum 7W per module
Environmental Parameters:
- Operating Temperature: -20℃ to +70℃ (-4℉ to +158℉)
- Relative Humidity: 5% to 95% (non-condensing)
- Storage Temperature: -40℃ to +70℃ (-40℉ to +158℉)
- Pollution Degree: Suitable for G3 level (harsh) environments
Physical Parameters:
- Installation Method: Modular backplane
- Dimensions: 102mm (4 inches) in height × 45mm (1.75 inches) in width × 104mm (4.11 inches) in depth
- Weight: Approximately 284g (10 ounces) per module
- Cable: RJ-45 connector, length from 1m (3.3 feet) to 100m (330 feet)
