GE IS210MACCH2A | IS210MACCH2AGG GE ENERGY PCB

• Input Voltage: 24V DC (marked by some suppliers, subject to official confirmation).
• Communication Interfaces: Supports industrial protocols such as RS-485 and Canopen, enabling data interaction with other devices.
• Processing Capacity: Equipped with a high-performance microcontroller, capable of handling real-time control algorithms and data acquisition tasks.

• Dimensions:
  • Some suppliers mark it as 263mm × 58mm × 28mm (including the housing).
  • Another source shows 12.7cm × 9.5cm × 2.5cm (may be the size of the module itself).
• Weight:
  • 4.3 kg (including packaging).
  • 0.2 kg (module itself).
• Installation Method: Card-insert design, compatible with standard industrial racks.

• Operating Temperature: -40°C to +70°C (referring to modules of the same series, such as IS210SAMBH2AA).
• Humidity: 10% to 90% (non-condensing).

II. IS210MACCH2AGG Parameters

• Communication Interfaces:
  • PCIe 3.0 x16 interface, supporting 10GbE high-speed Ethernet.
  • SFP+ optical module with a throughput of up to 10 Gbps (full duplex).
• Protocol Support: TCP/IP, UDP, IPsec, etc., compatible with VLAN tagging and flow control.
• Data Buffer: 256 KB buffer, supporting jumbo frames to improve large data transmission efficiency.

• Dimensions: Not clearly marked, but referring to modules of the same series (such as IS210MACCH2AKH), it is estimated to be approximately 14.8cm × 10.3cm × 3.2cm.
• Weight: Approximately 0.24 kg (module itself).
• Installation Method: Direct insertion into PCIe slots, compatible with industrial control chassis.

• Operating Temperature: 0°C to 55°C (marked by some suppliers, subject to version differences).
• Humidity: 10% to 90% (non-condensing).

Application Scenarios
Industrial network communication, multi-device collaborative control, data center edge computing, etc.
