Product Overview
Honeywell 05701-A-0550 is a high-reliability calibration plug specifically designed for the System 57 gas detection system. It simulates specific gas
concentration signals to enable accurate calibration of the detection system, ensuring reliable performance in industrial safety monitoring.
With rugged construction and stable electrical properties, this accessory is engineered for harsh industrial environments, providing long-lasting support for gas leak detection and process control.
Key Specifications
Power Supply: 24 VDC (compatible with standard industrial power setups)
Power Consumption: ≤ 20 W (energy-efficient design)
Environmental Ratings:
- Operating Temperature: -40°C to 85°C
- Storage Temperature: -55°C to 125°C
- Humidity: 5% – 95% (non-condensing)
- Protection Class: IP67 (dustproof and waterproof)
Electrical Performance:
- Insulation Resistance: ≥ 100 MΩ
- Withstand Voltage: AC 500V for 1 minute
- Response Time: < 30 seconds
Physical Dimensions: 55mm x 55mm x 16mm (compact for easy installation)
Weight: 0.25 kg
Connection Type: G1/4 external thread
Output Signal: 4-20mA
Core Features
Precise calibration for System 57 gas detection systems, ensuring measurement accuracy
Dual functionality: supports system calibration and auxiliary fault diagnosis
Rugged stainless steel housing resists dust, moisture, and extreme temperatures
Plug-and-play design for quick integration and minimal downtime
High electrical stability reduces frequent replacement and maintenance costs
Application Fields
Ideal for industries requiring reliable gas detection and process control:
Oil and gas (refineries, drilling platforms)
Chemical manufacturing and storage
Metallurgy (high-temperature, dusty environments)
Power generation (gas-fired power plants)
Environmental monitoring and industrial safety systems
Quality & Warranty
Manufactured to Honeywell’s strict quality control standards
CE certified, compliant with industrial safety and EMC directives
12-month warranty against non-human-induced defects
Factory-calibrated for immediate use upon delivery
