ABB 3HAC11510-1 Controller module Analog output board card

ABB 3HAC11510 – 1 is an analog output board card belonging to the category of controller modules.

Electrical Parameters

• Output Signal Range
  • Current Output: Commonly 4 – 20mA, and other ranges such as 0 – 20mA may also be supported.
  • Voltage Output: For example, 0 – 10V, – 10V – +10V, etc.
• Output Accuracy: Generally between ±0.1% – ±0.5%. High-precision products may achieve a higher accuracy level, and this accuracy determines how close the output signal is to the set value.
• Resolution: Usually 12 bits, 14 bits, or 16 bits. A high resolution means that the output signal can be adjusted more finely.
• Load Capacity
  • When it comes to current output, there are certain requirements for the load resistance. For example, for a 4 – 20mA output, the load resistance may be between 0 – 500Ω.
  • When it comes to voltage output, there are corresponding limitations on the load capacitance and load resistance that can be driven.

Performance Parameters

• Update Rate: It refers to the speed at which the output signal is updated, and the unit may be Hz or milliseconds (ms). A faster update rate can meet the application scenarios with high real-time requirements.
• Settling Time: The time required for the output signal to reach a stable value from the moment it changes, generally ranging from a few milliseconds to dozens of milliseconds.
• Temperature Coefficient: It reflects the characteristic of the output signal changing with temperature, and the unit is usually ppm/℃ (parts per million per degree Celsius). A smaller temperature coefficient means that the output is less affected by temperature.

Physical Parameters

• Dimensions: The length, width, and height dimensions of the board card to fit into a specific installation space. For example, it may be 150mm in length, 100mm in width, and 25mm in height, etc.
• Weight: It is convenient for consideration during transportation and installation, and it is usually in grams (g) or kilograms (kg).
• Operating Temperature Range: The operating temperature range of general industrial-grade board cards is – 20℃ – +60℃ or – 40℃ – +85℃ to ensure normal operation in different industrial environments.
• Storage Temperature Range: It is wider than the operating temperature range, for example, – 40℃ – +100℃.
• Humidity Range: The relative humidity is usually between 5% – 95% (non-condensing).

Interface Parameters

• Communication Interface: It may support communication methods such as RS – 232, RS – 485, CAN bus, Ethernet, etc., for data transmission with the controller or other devices.
• Connection Method: The connection method between the board card and external devices, such as plug-in connectors, welded connections, etc.
