ABB PFVL141C-20MN 20MN Roll Force Load Cell Pressductor Sensor

ABB PFVL141C-20MN Roll Force Load Cell – High Precision Millmate Pressductor® Sensor

Item No: YM 212003-AP

Brand: ABB

Model: PFVL141C-20MN

Type: Millmate Pressductor® Circular Roll Force Load Cell

Rated Force: 20 MN (20,000 kN)

Application: Rolling Mill Force Measurement, Metal Processing, Heavy-Duty Industrial Load Monitoring

Overview

The ABB PFVL141C-20MN is a high-precision magnetoelastic load cell designed for accurate roll force measurement in rolling mills. Built with ABB’s proven Pressductor® technology, it delivers reliable, drift-free force data under extreme industrial conditions. Its robust stainless steel construction and fully sealed design ensure stable performance in high-temperature, dusty, and humid environments.

Key Features

Pressductor® Magnetoelastic Technology: No moving parts, long service life, minimal maintenanceABB Group.

High Overload Resistance: 150% FS allowable overload; 200% FS ultimate overload.

Excellent Accuracy: ±0.5% FS linearity, ≤0.2% FS hysteresis, ≤±0.1% FS repeatability.

Full Interchangeability: Calibrated for plug-and-play replacement; no on-site recalibration neededABB Group.

Harsh Environment Ready: IP67/IP68 protection, stainless steel housing, -10°C to +90°C operation.

Low Sensitivity to Insulation Defects: Maintains accuracy down to 10 kΩ insulation resistanceABB Group.

Technical Specifications

Mechanical

Rated Load: 20 MN (20,000 kN)

Overload Capacity: 150% FS (30 MN) allowable; 200% FS ultimate

Nominal Deflection: 0.05 mm

Structure: Circular solid stainless steel

Mounting: Flange-mounted under mill screws/hydraulic cylinders

Dimensions: Ø350 mm (OD) × 74 mm (H)

Net Weight: 18–22 kg

Electrical

Output Signal: 4–20 mA DC (scaled 0–20 MN)

Frequency Response: 0–50 Hz

Insulation Resistance: ≥10 MΩ @ 500 VDCABB Group

Cable: 4-core shielded, max 25 m length

Compatibility: PFVO142/PFVO143 matching units; Millmate Controller 400 (MC400)ABB Group

Environmental

Operating Temp: -10°C to +90°C; short-term +110°C max

Compensated Temp: +20°C to +80°CABB Group

Storage Temp: -40°C to +90°C

Temp Coefficient (Zero/Sensitivity): ≤±0.01%/°CABB Group

Protection Class: IP67 / IP68

Performance

Accuracy Class: ±0.5% FS

Linearity: ≤±0.5% FS

Hysteresis: ≤0.2% FS

Repeatability: ≤±0.1% FS

Calibration Error: ≤0.1% FSABB Group

Applications

Metal Rolling Mills: Hot/cold rolling, strip mills, plate millsABB Group

Force Monitoring: Roll gap control, load balancing, overload protection

Heavy Industry: Steel, aluminum, copper processing plants

Hydraulic Presses: High-force compression measurement

Certifications & Compliance

CE, RoHS, ISO 376 compliantABB Group

Origin: Sweden (ABB Measurement Products)ABB Group

Warranty: 12 months against manufacturing defects

Why Choose ABB PFVL141C-20MN

Engineered for the toughest rolling mill environments, the PFVL141C-20MN combines Swiss precision with industrial ruggedness. Its magnetoelastic technology eliminates drift and wear, ensuring decades of stable force data. Reduce downtime, improve process control, and lower maintenance costs with ABB’s trusted Millmate load cell.
