Woodward 5233-2089 ProTech 203 Overspeed Protection Module
SKU: 5233-2089
The Woodward 5233-2089 is the ProTech 203 series TMR turbine overspeed protection module developed by Woodward, a world-leading brand for turbomachinery control systems. Woodward 5233-2089 receives three independent MPU magnetic pickup speed signals, calculates rotational speed and acceleration separately via built-in hardware circuits, and adopts 2oo3 voting logic to realize reliable turbine overspeed trip protection. Woodward 5233-2089 is independent of the turbine governor system, serving as a dedicated safety protection device for steam turbines, gas turbines and generator sets to prevent overspeed damage during unit operation.
Woodward 5233-2089 integrates local display panel and operation keys. Operators can view real-time speed value, configure overspeed threshold, check fault alarm records and trip event history locally. Woodward 5233-2089 supports passive or active MPU signal input, and comes with 3 sets of Form C redundant trip relays. The module can record trip causes and event logs for post-fault analysis, widely applied in thermal power plants, oil & gas industry, CHP cogeneration stations and industrial turbomachinery safety retrofit projects.
Key Features of Woodward 5233-2089
Model: Woodward 5233-2089, ProTech 203 Turbine Overspeed Protection Module
Triple modular redundant (TMR) architecture, 2 out of 3 voting logic
3-channel independent MPU speed signal input (support active & passive pickup)
Independent safety protection, separated from turbine speed governor
Built-in display & keypad for local parameter setup and real-time speed monitoring
3 x Form C redundant trip relay outputs for turbine trip control
Overspeed threshold adjustable: 0~150% full scale speed
Event & trip history logging for post-fault diagnosis
Rack mounting design, suitable for control cabinet installation
Rugged industrial hardware, anti-vibration, anti-electromagnetic interference
Technical Specifications
| Item | Parameter |
|---|---|
| Part Number | 5233-2089 |
| Product Name | ProTech 203 Turbine Overspeed Protection Module |
| Brand | Woodward |
| Series | ProTech 203 |
| Architecture | TMR Triple Modular Redundancy, 2oo3 Voting |
| Speed Input | 3 channels MPU magnetic pickup, active / passive compatible |
| Overspeed Setting Range | 0 ~150% FS Rotational Speed |
| Relay Output | 3 sets Form C Trip Relays |
| Power Supply | 220 VAC |
| Display | Local panel display + operation keypad |
| Mounting | Rack Mount / Cabinet Mount |
| Protection Grade | Front Panel NEMA 4X |
| Operating Temperature | -20℃ ~ +70℃ |
| Storage Temperature | -40℃ ~ +85℃ |
| Humidity | 5%–95% RH, non-condensing |
| Core Function | Turbine overspeed protection, speed monitoring, trip event recording |
| Certification | CE, UL |
Application Scenarios
Steam turbine & gas turbine overspeed safety protection
Thermal power plant turbogenerator set
Oil & gas compressor turbine control system
CHP combined heat and power station
Industrial generator overspeed protection retrofit
Power plant safety system upgrade project
Package & Warranty
Package: Anti-static foam + heavy export carton
Condition: New / Refurbished available
Warranty: 12 months warranty
Delivery: Fast worldwide shipping
