ABB DSRF197 3BSE019297R1 | S800 I/O Equipment Frame (Rack/Chassis)
ABB DSRF197 3BSE019297R1 is a redundant I/O equipment frame (rack/chassis) for ABB AC 800M controllers (800xA DCS). It provides mechanical mounting, dual redundant backplane wiring, and power distribution for S800 I/O modules, serving as the core hardware carrier for high-availability industrial control systems.
Key Features
- Redundant I/O Frame Design: 19-inch 2U rack chassis with dual backplane for fault-tolerant I/O operation.
- 8-Slot Module Housing: Accommodates up to 8 S800 I/O modules (AI810, AO810, DI810, DO810).
- Industrial-Grade Construction: Heavy-duty metal frame for vibration resistance; IP20 front protection.
- Hot-Swap & Online Maintenance: Supports live module replacement without system shutdown.
- Integrated Backplane & Wiring: Dual signal paths and power distribution for redundant control.
- Seamless AC 800M Compatibility: Matches PM860/PM861/PM862 controllers in 800xA systems.
Technical Specifications
| Parameter | Details |
|---|---|
| Model | DSRF197 |
| Order Code | 3BSE019297R1 |
| Brand | ABB |
| Series | S800 I/O |
| Product Type | Redundant I/O Equipment Frame (Rack/Chassis) |
| Compatible Controllers | AC 800M (PM860/PM861/PM862), 800xA DCS |
| Module Slots | 8 slots for S800 I/O modules |
| Redundancy | Dual backplane, 1:1 redundancy support |
| Power Supply | 24 VDC (±10%) |
| Operating Temperature | -40°C to +70°C |
| Protection Class | IP20 (front) |
| Dimensions (W×H×D) | 482 mm × 88 mm × 305 mm (19” rack-mount, 2U) |
| Weight | 8.1 kg |
| Mounting | Standard 19-inch industrial cabinet |
Applications
- High-availability DCS/PLC systems in process industries.
- Oil & gas, chemical, power generation, pulp & paper, water treatment.
- Safety-critical control loops requiring 100% uptime.
- Industrial automation retrofits and redundant system upgrades.
