ABB CCF10-P (3BDH000508R1) is a high-performance Modbus coupling module for ABB DCS/SIS platforms, enabling seamless serial-to-Ethernet protocol conversion and reliable data exchange in industrial automation. As a core communication gateway, the CCF10-P integrates legacy Modbus RTU/ASCII devices with modern Modbus TCP networks, critical for process control, power, and oil & gas systems.
Key Features
Modbus Protocol Conversion: Transparent bridge between Modbus RTU/ASCII (serial) and Modbus TCP (Ethernet); supports master/slave modes.
Multi-Interface Connectivity: RS-232/RS-422/RS-485 serial ports (galvanic isolation); 1× Ethernet 10/100 Mbps for TCP/IP.
Industrial-Grade Reliability: Rugged metal housing; surge/EMI protection; -20°C to +60°C operation; IP20 protection.
Easy Configuration: Built-in web server for setup; supports 300–19200 baud rates; multi-TCP connection support.
Seamless ABB Integration: Compatible with ABB 800xA, Symphony Plus, Freelance DCS; ideal for S800 I/O and AC800M controllers.
Technical Specifications
| Parameter | Details |
|---|---|
| Model | CCF10-P |
| Part Number | 3BDH000508R1 |
| Function | Modbus Serial-to-TCP Coupling Module |
| Protocols | Modbus RTU/ASCII (serial), Modbus TCP (Ethernet) |
| Interfaces | 1× Ethernet (10/100 Mbps), RS-232/422/485 (isolated) |
| Baud Rates | 300–19200 bps |
| Power Supply | 24 VDC (19.2–30 VDC range), ~260 mA |
| Operating Temp | -20°C to +60°C |
| Dimensions | 120×80×40 mm (W×H×D) |
| Weight | ~0.6 kg |
| Protection | IP20, surge/EMI shielding, galvanic isolation |
| Compatibility | ABB 800xA, Symphony Plus, Freelance, S800 I/O, AC800M |
Applications
Power Generation: DCS communication for turbine control, boiler safety, and substation monitoring.
Oil & Gas: ESD system data exchange, pipeline monitoring, and offshore platform automation.
Chemical & Petrochemical: Process safety control, furnace/BMS integration, and legacy device connectivity.
Industrial Automation: Factory floor I/O networking, SCADA integration, and remote monitoring solutions.
Why Choose ABB CCF10-P 3BDH000508R1
The ABB CCF10-P 3BDH000508R1 is a robust Modbus coupling module that ensures reliable, high-speed data transfer between serial and Ethernet networks. Its rugged design, wide temperature range, and seamless ABB DCS/SIS compatibility make it essential for critical industrial applications, reducing downtime and enhancing system interoperability.
